Products |  |
 |
|||
 |
Orbital Shaking Incubators |  |
|
| Our company also takes pride in providing a wide range of orbital shaker .These are designed & fabricated to suit various is standard of orbital shaking motion applicable in growing field of medical agricultural industrial Research Laboratories & Others. Products are orbital shaking incubators, laboratory bacteriological incubator, bod incubator exporters, laboratory bod incubator manufacturers, industrial oven wholesale suppliers, vertical autoclave exporters, muffle furnace suppliers india, round vaccum oven manufacturers, laboratory muffle furnace manufacturers. Technical Specifications: • Double walled inner chamber made of S.S.304 & outer M. S. Powder coated. • PUF insulation between two walled • Heavy angle frame structure from all sides • Shaking assembly electric pulley mechanism • Platform adjustable stainless steel platform • Flask Holder: Spring type clamp arrangement with easy interchangeability facility. • Motor (PMDC Motor) • RPM 50 to 250 RPM controlled by Regulator • Stroke 25 to 30 mm Stroke displacement • Temp. Controlled by digital Temp. Controller cum indicator with accuracy of ±0.5 ˚C • Temp. Range 10 ˚C to 60 ˚C in cooling Model & in heating Model 5 ˚C above ambient to 60 ˚C. • Cooling by CFC free hermetically sealed compressor • Heating by ‘U’ Type tubular S. S. Heater • Illumination light to view. Optional Accessories: • RPM Indicator in digital Display • Digital timer with Audio visual Alarm • Chamber illumination with U. V. Tube • Additional tray as per Flask Size. Size available for orbital Incubator
|
  )   |
 |
|||
 |
Memmert Type Bacterological Incubator | |
|
) |
Our company has specialized in the sphere of fabricating a wide range of Memmert Incubators that is sturdy in construction & durable. We used high grade raw materials that is procured from the renowned vendors of the country for the mgf. process for ensuring high efficiency of the memmert incubators. Available in different sizes, we can also customize these incubator as per the requirement of Clients. Specifications: • Triple walled Unit. • Inner chamber made of S.S.304 • Outer chamber of Mild Steel with Powder coating. • Gap Between the two walls filled with glass wool insulation to avoid heat loses of 65 mm • Heating element Are Made of high grade chrome plated nichrome wire. • Heaters are placed ate the right & left side of the inner chamber • Enable with thermostat control the Temperature Temp. Range 5 ˚C above ambient to 60 ˚C accuracy ±2 ˚C • Air Ventilation is placed on top of both sides to remove heat gases and fumes. • Control Switch & pilot lamps are fitted on front panel • Supplied with G.I. Wire mesh Jali. Memmert Incubator is available in below sizes:
Optional Accessories: • Digital Temp. Controller cum indicator in Live of thermostat with Accuracy ± 0.5 ˚C • Air circulation Fan for Uniform Temp • S. S. Rod Type Jali • Digital Timer |
|
|||
|
BOD Incubator | |
|
| Our extensive range of B.O.D. Incubators has been designed especially for biological Oxygen demand determination & other applications like general incubators, Serum studies & Enzyme assays test. We can also customize the B.O.D. Incubators to suit the varied requirement of the clients with in stipulated time frame. Technical Specifications: • Double walled cabinet mounted on castor wheels • Inner chamber made of S.S.304 & Outer chamber made of M. S. Powder coated • Full Length inner acrylic door permit inspection of specimens with out disturbing the Temp. • Temp. Controlled by solid State Digital controllers housing all the control with PT-100 sensor illumination light are provided for viewing with door limit switch. • CFC Free hermetically sealed compressor provide temp. For below ambient condition. • Air circulation fan for maintain Temp. Uniformity through out the chamber. • Flush fitting insulated double walled door • The Chamber is provided with modular removable shelves made of S. S. For complete flexibility in use • To work on 230 volts 50 H2. Validation Protocols : IQ OQ & PQ Documentation with calibration & Tradability certificate of controller. Safety Features : Built in Temp Deviation Audio visual alarm, Safety thermostat for overshoot Temp. Cut off system. HRC Fuses for compressor heater & mains Time daily circuit for safety of compressor. Special Care : A suitable K V. A. Servo stabilizer is strongly recommended. This B.O.D.incubator Is available in below sizes
|
) |
|
|||
|
Industrial Oven | |
|
) |
This industrial oven is specially designed as per guideline of GMP supplied with IQ, OQ & PQ Document with caplibaration report for PID Controller. Technical specifications: • Triple Walled construction. • Inner made of S.S.316 Mirror polished • Outer made of S.S.304 Dull finish. • Gap Between the two walled filled with high grade glass wool insulation of 65 mm • Heating Element is made of S.S. ‘U’ type tubular Nichrome wire with S.S. Sheathing. • Heaters are placed at the right & left side of the inner chamber. • PID Controller with auto tuning facility with double display to view set & current temp. • Temp. Range 50 ˚C to 250 ˚C • Silicon rubber gasket fitted on door to prevent lost of heat. • Control Switch & pilot lamp are fitted on front panel supplied with S.S. Rod Type Jali.
Optional accessories: • Digital timer to cut off the heater at set intervals PID controller with printer interface to record set valves & actual valves data 7 Timer. • Single 4 point/8 point data logger. • Air circulation for uniform Temp. Throughout chamber. |
|
|||
|
Vertical Autoclave | |
|
| Automatic vertical autoclaves are specially designed for medical clinical bacterogical & research laboratories Pharmaceuticals, Fertilizer Plant, Breweries soft Drink mfg. etc. Technical Specifications: • Double walled construction outer M.S/S.S.304 & Inner S.S.304 with heavy Gauge & Argon Walled • Lid is made of S.S.304 heavy gauge die pressed • Equipped with pressure gauge, steam release valve & 2 Safety valves • This instrument supplied with S. S. perforated basket • It is used for sterilization under working steam pressure upto 15 PSI • Fitted with silicon rubber gasket joint less • Work in 230 Volts 50 H2 • Foot lifting arrangement to open lid Optional Accessories: • Pressure cut off Switch • Water Level cut off • Digital Timer • Microprocessor controller with printer Interface Different size available for Autoclave as below:
|
) |
|
|||
|
Muffle Furnace | |
|
) |
Industrial muffle furnaces are specially designed to suit IS & ASTM Standard. IT is applied in growing fields of Medical research, agricultural, industrial, metal treatment, ash determination & wool industries. Technical Specification: • Outside Body made of G.I. Sheet powder coated • Inner muffle of Ceramic with high grade ceramic instillation • Door insulation of HFK briks • Heating element are made from kanthal A1 Wire • A Uniform distribution through all 4 sides with kentahl wire • Max. Working temp upto 1160 ˚C • Equipped with digital temp. Controller cum indicator fitted on top side of the unit with indicating lamps & switches • A special type of thermocouple fuse for safety to avoid over heating • Power supply 230 Volts, 50 H2 Optional Accessories: • Digital Timer • Solid state fuses for extra safety • PID Controller with printer interface. Sizes available for industrial muffle furnaces are as below.
|
|
||||||||||||||||||||||||||||||||||||||
